CISCO NEXUS N9K-9372PX-E
| Name: |
N9K-C9372PX-E |
| Model: | N9K-C9372PX-E - Cisco Nexus 9000 Series Switch |
| Detail: |
Nexus 9300 Switch with 48p 10G SFP+ and 6p 40G QSFP+, a minor hardware revision of Nexus 9372PX
|
| Condition: | Used A++ |
N9K-C9372PX-E Overview
Cisco Nexus 9372PX-E Switch (N9K-C9372PX-E) is a minor hardware revision of the Cisco Nexus 9372PX. Enhancements include hardware capability for IP-based endpoint group (EPG) classification in Cisco ACI mode.
Quick Specs:
Figure shows the appearance of the N9K-C9372PX-E.
|
Product Code |
N9K-C9372PX-E |
|
Ports |
48 fixed 1/10GBASE-T and 6 QSFP+ ports |
|
Form factor |
1 RU |
|
Throughput (Tbps) |
1.44 |
|
Supported speeds |
1/10 Gigabit Ethernet speeds |
|
40 Gigabit Ethernet uplink port |
6 fixed QSFP+ ports ·Advanced QSFP+ optics enable connectivity using existing 10 Gigabit Ethernet fiber.·The switch offers 25 MB of additional packet buffer space shared with all ports for more resilient operations |
|
Typical power(AC & DC) |
210W |
|
Maximum power(AC & DC) |
537W |
|
Maximum number of longest prefix match (LPM) routes |
128,000 |
|
CPU, SSD, and memory |
Dual-core 2.5-GHz x86 CPUs with 64-GB SSD drive and 16 GB of memory provide enhanced network performance. |
|
Buffer (MB) |
37 |
|
Operating System |
NX-OS, ACI |
|
Fans |
4 |
|
Physical (H x W x D) |
1.72 x 17.3 x 22.5 in. (4.4 x 43.9 x 57.1 cm) |
|
Acoustics |
48.5 dBA at 40% fan speed, 64.9 dBA at 70% fan speed, and 77.8 dB at 100% fan speed |
|
Weight（without power supplies or fans） |
22.2 lb (10.1 kg) |
